EcoShield® Heat Sealable Paper is a packaging material covered with water-based heat sealable adhesives.
Seams made from correctly sealed goods (heated with coated edges together) have greater adhesion than paper.
EcoShield® Heat Sealable Paper is recyclable and repulpable.
CorShield® VpCI® 146 Paper is a heat sealable and corrosion-inhibitory variant of this paper.
Packaging & Storage of Heat Sealable Paper
The Heat Sealable Paper is available in different packages. You can choose between 600' (182.88 m) and longer stock rolls (36" to 48" or 1.22 m wide).
Custom sizes are also available. Sizes can be up to 68" (1.73 m) wide on request.
Store in original packaging indoors at 4-100 °F (4-38 °C) for guaranteed optimal product performance. Keep it out of direct sunlight.
Shelf life: 2 years
Features
• Completely recyclable (repulpable).
• Non-hazardous.
• Printable.
• Conform to being environmentally responsible.
• Creates a strong permanent adhesion between coated surfaces.
Typical Properties
|
Property |
TAPPI |
Unit |
EcoShield® N45 Paper |
|
Basis Weight |
T-410 |
lb/3,000 ft2 (g/m2) |
35±1 (60±2) |
|
Base Stock |
T-410 |
lb/3,000 ft2 (g/m2) |
37 (60) |
|
Caliper |
T-411 |
Mil (µm) |
3.75±0.5 (93.5±12) |
|
Brightness |
T-452 |
% |
92 |
|
Seal Strength |
ASTM F88-99 |
lb/in (N/25.4 mm) |
1.2±0.3 (5.2±1.3) |
Application
EcoShield® Heat Sealable Sheets can be used to create bags and envelopes. Suggested heat seal temperature is at least 250 °F (120 °C). Sealing times may differ using appropriate sealing equipment.
CorShield® VpCI®-146 can be cut into customised heat-sealable packs and bags to wrap and protect metal components from corrosion.
